CCTV Tester, 3.5"tft-LCD, Digital Multimeter, Video Level Testing, PTZ Controller,
DC12V 1a Power Out pour Camera, All in One CCtv Test Monitor
Description
* Signal model: NTSC/PAL (Auto Adjust)
* Display: 3.5 inch TFT-LCD, 960 x 240 resolution
* LCD adjust: Adjustable brightness, contrast, color of LCD
* Video IN/OUT: 1 channel BNC Input & 1 channel Output
* Video Level test: Video signals measured in IRE or mV
* Power output: DC12V, 1A
* Audio input: 1 channel Audio input
* Communication: RS232, RS422 simplex and RS485
* Baud Rate: 150, 300, 600, 1200, 2400, 4800, 9600, 19200bps
* Power Adapter: DC5V, 2A
* Low Consumption: Sleeping mode, display batterie power state
* PTZ address scanning : Search up the ID of PTZ camera
* Rechargeable: 4 hours recharging time, work pour 12 hours
* batterie: 1 pcs Lithium Ion Polymer Batteries, 3.7V DC 3000mAh
* Video Signal Generation: Output 1 channel color bar video signal pour testing monitor
* UTP cable test: Test UTP cable connection state and display in the screen. Read the number of the test box
* PTZ Protocol: Compatible with more than 20 protocols such as PELCO-D/P, Samsung, Panasonic etc.
* PTZ data Capture and display: Capture and Analyze the PTZ data sent from controlling device
* Dimension/Weight: 94mm x 175mm x 40mm / 360g
* MultiMeter: Voltage, current, resistance and capacitance measuring, continuity testing, diode testing
STest-894 CCTV Security Tester.
